EC050520H

Configuration: Single blank door

ETA E CORX Unibody wall-mount enclosure, concealed hinge, double-bit 1/4-turn latch, NEMA/UL TYPE 1, 12, 4x; IP66, AISI316L stainless steel, Single Solid Door, 20 x 20 x 8\ (500 x 500 x 200mm - HxWxD)”

Height*500
Width*500
Depth*200
* Dimensions mm (nominal inches)

Material

AISI316L stainless steel

Certifications

CE-UKCA - RINA - cULus Listed - EAC - RoHS

Resources

ECOR_X_single_door.dwgECOR_X_single_door.dxfECOR_X_single_door.pdf 3D CAD Catalog
Door typeSingle blank
Environmental ratingsNEMA/UL TYPE 1, 12, 4x, 3R; IP66
Family/SeriesECOR(X)"""
Manufacturer IDEC050520H
HxWxD (mm)500X500X200
Latch typeQuarter-turn, double-bit key
# of Latches1
Product materialAISI 316L
ThicknessEnclosure: 1,2mm Door: 1,5mm Mounting plate: 2,5mm
Impact ratingIK10
ContentsEnclosure, double-bit key, mounting plate, and hardware for grounding and mounting plate
Package quantity1 pc.
PackagingETA light blue cardboard box
Weight15.1
Weight net14.3
HTS (Customs)85381000
Capacityecorx-group.png,ecorx-features-a.png,ecorx-features-b.png,ecorx-features-c.png,ecorx-features-d.png
