FranceSBA Monobloc Control Desks
Technical features
Material
- enclosure and doors (front and rear): press-folded DC01 sheet steel
- upper panel: sheet steel
top plate: sendzimir sheet steel - thickness: enclosure and door: 1.5mm, base plate: 2.5mm
Painting: standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders.
Colour: RAL7035 textured
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance rating: IK10
Supply
- enclosure
- door with lateral stiffening band and complete with 3.0 mm diameter double flap locking system
- upper panel with profiles and gas springs to prevent accidental closure
depth adjustable p.a. plate - adjustable cable entry
ZBA Control desk
Technical features
Material
- enclosure and door: press-folded DC01 sheet steel
- upper panel: sheet steel
- profiles and base plate: sendzimir sheet steel
- thickness: casing 1.5 mm, door 1.5 mm, top panel 1.5 mm, base plate 2.5 mm
Painting: standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders.
Colour: RAL7035 textured
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance degree: IK10
Supply
- enclosure
- door with lateral stiffening band, complete with 3.0 mm diameter double flap locking system
- upper panel complete with profiles and mechanical opening stop, with locking system
- mounting plate fixed to the rear wall
- adjustable cable entry
Monobloc Control Desks
Code List
Filter by:
Width (mm)
600
800
1000
1200
Height (mm)
1000
| Item # | Configuration | Height | Width | Depth | Add to Quote Cart |
|---|---|---|---|---|---|
| SBA001 | Single-bay Console | 1000 | 1000 | 500 | |
| SBA201 | Single-bay Console | 1000 | 1200 | 500 | |
| SBA601 | Single-bay Console | 1000 | 600 | 500 | |
| SBA801 | Single-bay Console | 1000 | 800 | 500 | |
| ZBA001 | Double-bay Console | 1000 | 1000 | 505 | |
| ZBA201 | Double-bay Console | 1000 | 1200 | 505 | |
| ZBA601 | Double-bay Console | 1000 | 600 | 505 | |
| ZBA801 | Double-bay Console | 1000 | 800 | 505 |
Contact our team of experts to discuss your project requirements and request a quote today.
