Electrical Enclosure Cooling & Filter Fans

WTSV fans and WTSG filter grids are the first line of defense against overheating in many industrial environments. They provide essential airflow, ensuring that heat generated by equipment is dissipated efficiently, maintaining a favorable environment inside the cabinet.

Proper air recirculation optimizes cost and time, preserving the optimal operation of electrical equipment inside the cabinet.

Enclosure Cooling Fans

Technical features

Material: ABS BLEND (RAL7035)


Optimal airflow: designed to provide the right amount of airflow, ensuring efficient heat dissipation.

  • Airflow rate: 35 to 850 m3/h
  • MTBF: 40000 H
  • Power supply: single-phase, 230 V, 50-60 Hz (three-phase, 400-460V on request)

Dust and debris filtration: Built-in filters ensure the removal of contaminants, maintaining a clean indoor environment.

Energy efficiency: Our fans are designed to operate with minimal energy consumption, providing savings in operating costs.

Easy maintenance

  • easy grille opening for filter replacement/cleaning
  • screwless fixing system
    possibility of ordering replacement air filter made of chemical fibers

Degree of protection: IP54, NEMA 12

Cooling Fans & Filters

Code List

Filter by:

Configuration
FAN 119X119 35M3/H 230V
FAN 119X119 50M3/H 115V
FAN 119X119 50M3/H 24V
FAN 152X152 67M3/H 115V
FAN 152X152 67M3/H 230V
FAN 152X152 67M3/H 24V
FAN 204X204 108M3/H 115V
FAN 204X204 108M3/H 230V
FAN 204X204 108M3/H 24V
FAN 250X250 190M3/H 115V
FAN 250X250 190M3/H 230V
FAN 250X250 230M3/H 24V
FAN 250X250 270M3/H 115V
FAN 250X250 270M3/H 230V
FAN 318X318 500M3/H 115V
FAN 318X318 500M3/H 230V
FAN 318X318 700M3/H 230V
FAN 318X318 850M3/H 115V
FAN 318X318 850M3/H 230V
FAN 318X318 850M3/H 400V
VENTILATION GRID 119X119
VENTILATION GRID 152X152
VENTILATION GRID 204X204
VENTILATION GRID 250X250
VENTILATION GRID 318X318
Height (mm)
119
152
204
250
318
Width (mm)
119
152
204
250
318
Depth (mm)
5
28
32
33
34
47
57.5
75
98
99
118
135
139
160.5
Environmental Ratings
IP20
IP43/Type1
IP44
IP54
Item #ConfigurationHeightWidthDepthEnvironmental ratingsAdd to Quote Cart
WTSG10VENTILATION GRID 119X119 11911928,5IP44
WTSG15VENTILATION GRID 152X152 15215232,5IP44
WTSG20VENTILATION GRID 204X204 20420433,5IP20
WTSG25VENTILATION GRID 250X250 25025047,5IP20
WTSG30VENTILATION GRID 318X318 31831834IP20
WTSV1000203FAN 119X119 50M3/H 115V 11911957.5IP20
WTSV1000211FAN 119X119 50M3/H 24V 11911957.5IP20
WTSV1000220FAN 119X119 35M3/H 230V 11911957.5IP20
WTSV1500203FAN 152X152 67M3/H 115V 15215275IP20
WTSV1500211FAN 152X152 67M3/H 24V 15215275IP43/Type1
WTSV1500220FAN 152X152 67M3/H 230V 15215275IP43/Type1
WTSV2000203FAN 204X204 108M3/H 115V 20420498IP43/Type1
WTSV2000211FAN 204X204 108M3/H 24V 20420498IP43/Type1
WTSV2000220FAN 204X204 108M3/H 230V 20420498IP43/Type1
WTSV2500203FAN 250X250 190M3/H 115V 250250118IP43/Type1
WTSV2500211FAN 250X250 230M3/H 24V 250250118IP54
WTSV2500220FAN 250X250 190M3/H 230V 250250118IP54
WTSV2501203FAN 250X250 270M3/H 115V 25025099IP54
WTSV2501220FAN 250X250 270M3/H 230V 25025099IP54
WTSV3000203FAN 318X318 500M3/H 115V 318318139IP54
WTSV3000220FAN 318X318 500M3/H 230V 318318139IP54
WTSV3001203FAN 318X318 500M3/H 115V 318318135IP54
WTSV3001220FAN 318X318 700M3/H 230V 318318135IP54
WTSV3002203FAN 318X318 850M3/H 115V 318318160.5IP54
WTSV3002220FAN 318X318 850M3/H 230V 318318160.5IP54
WTSV3002262FAN 318X318 850M3/H 400V 318318160.5IP54
